Replacing Eaton 300188 01. E 240.10VG. HR. E.P oil filter uses multi-layer compo
Model: 300188 01.E 240.10VG.HR.E.P
Filtration Accuracy: 10um
Brand: HYFILTRATE
Material: Fiberglass
Outer diameter: Standard size
High: Standard size
Replacing Eaton 300188 01. E 240.10VG. HR. E.P oil filter uses multi-layer composite filter materials with a filtration accuracy of up to 10um, which can effectively intercept particulate pollutants such as metal debris and dust in hydraulic systems, significantly reducing equipment wear. The capture efficiency of target particles exceeds 99.5%, far exceeding the 80% -90% of ordinary filter cartridges. The unique gradient density design ensures that pollutants are evenly distributed in the filter material, avoiding local blockage and extending its service life.
Replaces Eaton 300188 01.E 240.10VG.HR.E.P oil filter
Filtering accuracy: The nominal filtering accuracy is 10um, and the actual interception efficiency is 99.5%, which can effectively capture particulate pollutants in hydraulic oil.
Flow characteristics: The rated flow rate is 240L/min, the peak flow rate can reach 300L/min, and the pressure difference curve shows a pressure rise rate of ≤ 0.03MPa/100h in saturation state.
Pressure resistance level: working pressure 42MPa, burst pressure ≥ 84MPa, valve opening pressure set at 0.15 ± 0.02MPa,
Pollutant holding capacity: The pollutant holding capacity is ≥ 12g, which is 20% higher than similar products, thanks to the gradient density filter layer structure and the optimized ratio of coarse and fine filter layers.
